ASTM B148 C95800 Gate Valve, 48 IN, CL 300, Bolted Bonnet

Key Specifications / Features

Model no. : 1821084

We are a trusted exporter of aluminum bronze gate valves from China, offering top-quality valves with an ASTM B148 C95800 body. Designed to meet API 600 standards, our 48-inch (DN1200) gate valves are rated for 300 LB (PN50) and feature RF flanged ends for reliable connections. Equipped with OS&Y and a screwed-in back seat, these valves ensure robust performance in demanding industrial applications. Built for durability and precision, our aluminum bronze gate valves provide excellent corrosion resistance and reliable flow control, making them ideal for various sectors worldwide.

Detail Information

48 Inch Gate Valve, ASTM B148 C95800 Body, DN1200, Class 300 LB, RF Flanged.

Valve Description

1821084 Gate Valve
Design Standard: API 600
Body Material: ASTM B148 C95800, ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A
Nominal Size: 48 Inch, DN1200
Nominal Class: 300 LB, PN50
Structure: Bolted Bonnet/Pressure Seal Bonnet
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Face to Face: ASME B16.10
End Connection: RF Flanged
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Working Temperature: -29°C - +400°C
