Key Specifications / Features
The 1841079 Swing Check Valve is engineered to meet BS 1868, API 594, and API 6D standards, ensuring reliability in demanding industrial settings. This Class 600 LB valve features a substantial 36-inch size with a bolted bonnet and RF flanged end connection for secure installation. Constructed from ASTM B148 C95800 alloy and offering Trim options including ASTM A182 F6A, F304, F316, it combines durability with performance. With gear operation and optional lever design, it supports both standard bore (BS 1868, API 594) and full bore (API 6D) configurations. Tested to API 598 standards and adhering to ASME B16.10 face-to-face dimensions, it ensures optimal operational efficiency.
Detail Information
API 594 Swing Check Valve, Bolted Bonnet, 36 Inch, 600 LB, Flanged, C95800 Alloy, Gear Operated.
Descriptions
1841079 Swing Check Valve
Design Standard: BS 1868, API 594, API 6D
Structure: Bolted Bonnet
Size: 36 Inch, DN900
Pressure: Class 600 LB, PN100
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
End Connection: RF Flanged
Operation: Gear
Body Material: ASTM B148 C95800, ASTM A351 CF8M, CF8, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Key Features: Bolted Bonnet, Full Opening design available, Operation Gear design Available
Face to Face: ASME B16.10
Test and Inspection: API 598
Product Line
Body Materials: Aluminum-bronze, Alloy Steel, Carbon Steel, Stainless Steel
Normal Diameter: 1/2 Inch - 48 Inch (DN15-DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working temperature: -196°C - +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
Operation: Not Applicable (Manual or actuated available for special request)
