ASTM A890 5A Wafer Butterfly Valve, API 609, CL300, 48 IN

Key Specifications / Features

Model no. : 1862326

As a trusted supplier of ASTM A890 5A wafer butterfly valves, we provide double eccentric valves designed to meet EN 593 and API 609 standards. Our 48-inch butterfly valves feature an ASTM A890 5A body for enhanced durability and corrosion resistance. Rated at Class 300 LB and PN50, these wafer-end valves are soft-seated to ensure reliable sealing. Ideal for isolation and regulating applications, our double offset design is perfect for pipelines that require frequent opening and closing, delivering optimal performance in demanding environments.

Detail Information

Double Eccentric High-Performance Butterfly Valve, ASTM A890 5A, 48 Inch/DN1200, RPTFE Seat.

Valve Description

1862326 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Nominal Size: 48 Inch, DN1200
Nominal Class: Class 300 LB, PN50
Body Material: ASTM A890 5A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM B148 C95800, Titanium, ASTM A890 4A.
Seat Type: Soft Seat
Operation: Lever
Structure: Double Offset, Double Eccentric
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium.

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: CL 150-300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
