Key Specifications / Features

Model no. : 1862058

As a leading manufacturer of RPTFE seated butterfly valves, we offer high-performance double offset valves designed to meet EN 593, API 609 Category B standards. Our 6-inch butterfly valves, made from ASTM A890 5A material, are rated for 300 LB and feature a durable 17-4PH stem. The wafer end configuration and gear-operated design provide smooth and reliable operation. Engineered for demanding applications, these valves deliver exceptional sealing and longevity, making them an excellent choice for industrial environments requiring high strength and performance.


Detail Information

High-Performance Butterfly Valve, 6 Inch, DN150, 300 LB, Soft Seat, Wafer End, Gear Operation.

Valve Description

1862058 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 6 Inch, DN150
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: ASTM A890 5A, ASTM A890 4A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM B148 C95800, Titanium.
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged

Double Eccentric Butterfly Valve Introduction

The double eccentric butterfly valve provides cost and space savings with a wide size range and faster operation. It minimizes wear and restriction between the disc and seat, ensuring a longer cycle life and lower total ownership costs. With its design offering extended operational life and reduced torque, it’s ideal for frequent use. The Bosseal high-performance valve has passed a million-cycle test, proving its durability.

Different End Connections Available

Different End Connections Available

Dead End Service

For valves installed at the end of a pipeline where one side has no connection to a pipe or flange, special design features such as threaded holes and bi-directional sealing are required.

Easy Maintenance

The valve features a replaceable seat that can be easily serviced. Simply loosen the seat retainer using specialized tools to disassemble and replace the seat.

Fire Safe Seat

Our valve includes a fire-safe seat design with dual seals: a primary soft PTFE seat and a secondary metal seat. In the event of a fire, if the soft seat is compromised, the metal seat ensures effective shut-off.
