ASTM A890 5A Butterfly Valve, 8IN, CL150, API 609 B, EN 593

Key Specifications / Features

Model no. : 1862332

As an API 609 Category B butterfly valve provider, we offer double offset and double eccentric designs that conform to EN 593 standards. Our 8-inch valves feature a Monel K500 stem and are constructed from ASTM A890 5A material, rated for 150 LB. Equipped with RPTFE seats, these valves ensure reliable sealing and robust performance in various applications. As a leading butterfly valve manufacturer in China, we deliver high-quality solutions that meet the highest industry standards for durability and efficiency.

Detail Information

API 609 Soft Seated Butterfly Valve, 8 Inch/DN200, Class 150 LB, RPTFE Seat.

Valve Description

1862332 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A890 5A, ASTM B148 C95800, ASTM A890 4A, Titanium, ASTM A351 CF8, ASTM A216 WCB, ASTM A351 CF8M.
Nominal Size: 8 Inch, DN200
Nominal Class: CL 150 LB, PN20
Seat Type: Soft Seat
Operation: Gear
Seat: RPTFE, PPL
End Connection: Lug
Structure: Double Offset, Double Eccentric
Trim Material: ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM B148 C95800, Titanium
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150/300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
Operation Types: Lever, Gear, Pneumatic Actuator
