ASTM A890 4A Wafer Butterfly Valve, 32IN, CL300, API 609

Key Specifications / Features

Model no. : 1862322

As a prominent API 609 Category B butterfly valve provider in China, we offer high-quality solutions designed to EN 593 standards. Our 32-inch valves feature a double eccentric design, crafted from durable ASTM A890 4A material for exceptional strength. With a Monel K500 stem and an RPTFE seat, these valves provide reliable sealing and resistance to corrosion. Rated at 300 LBS and equipped with wafer ends for straightforward installation, they are ideal for demanding applications requiring precise control and long-lasting performance.

Detail Information

Double Eccentric Butterfly Valve, 32 Inch, 300 LB, ASTM A890 4A Body, RPTFE Seated.

Valve Description

1862322 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A890 4A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, Titanium, ASTM B148 C95800.
Nominal Size: 32 Inch, DN800
Structure: Double Offset, Double Eccentric
Nominal Class: 300 LBS
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Wafer
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium.

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
