ASTM A890 4A Gate Valve, 6 Inch, 600 LB, OS&Y, API 600

Key Specifications / Features

Model no. : 1821089

As a leading duplex stainless steel gate valve exporter from China, we offer high-performance valves crafted for durability and reliability. Our 8-inch (DN200) gate valve features a robust ASTM A890 5A construction and adheres to API 600 standards. With a Class 300 LB rating and PN50 pressure class, it is designed for demanding applications. The valve includes a raised face (RF) flanged end, OS&Y mechanism, and a screwed-in back seat for enhanced functionality. Choose us for top-quality gate valves that meet rigorous industry standards and performance requirements.

Detail Information

API 600 Wedge Gate Valve, OS&Y, ASTM A890 4A Body, 6 Inch/DN150, 600 LB, RF Flanged.

Valve Description

1821089 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Bore Type: Standard Bore(API 600)
Body Material: ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M.
Nominal Size: 6 Inch, DN150
Nominal Class: CL 600 LB, PN100
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: RF Flanged

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Stem Types: Rising stem, Non-rising Stem
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
