ASTM A352 LCB Check Valve, 2-1/2 Inch, CL 900 LB, API 594

Key Specifications / Features

Model no. : 1842082

We are a premier manufacturer of carbon steel dual plate check valves, offering top-quality solutions that meet API 594 and API 6D standards. Our 2-1/2 inch (DN 65) valves are rated for Class 900 LB and PN 150, featuring a compact design with wafer, lug, and flanged end options for versatile installation. The dual plate mechanism is actuated by high-torsion springs, ensuring rapid closure and reducing water hammer effects. This design not only enhances sealing performance but also extends the valve’s operational lifespan. With a focus on precision engineering and durability, our check valves provide reliable, efficient performance for demanding industrial applications.

Detail Information

API 594 Dual Plate Check Valve, ASTM A352 LCB, 2-1/2 Inch/DN65, 900 LB, Compact Design, Flanged Ends.

Check Valve Specification

1842082 Dual Plate Check Valve
Design Standard: API 594, API 6D
Structure: Spring Loaded, Dual Plate
Key Features: Compact Design, Independent Spring, Optional Soft and Metal Seat, Unique Slim Plate Design.
Nominal Size: 2-1/2 Inch, DN65
Nominal Class: ANSI Class 900 LB, PN150
Body Material: ASTM A352 LCB, Titanium Alloy, ASTM A890 5A, ASTM A216 WCB, ASTM B148 C95800, ASTM A351 CF8, CF8M, ASTM A890 4A.
Bore Type: /
End Connection: Wafer, Lug, Double Flanged
Operation: /
Trim Material: ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, CF8M, ASTM A890 4A, 5A, ASTM B148 C95800, Titanium Alloy.
Face to Face: API 594
Test and Inspection: API 598

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Alloy Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 - 2500 LB
Working Temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Wafer, Lug, Flanged(FF, RF, RTJ), Butt Weld(BW), HUB
Seat Type: Soft Seat, Metal Seat
