ASTM A351 CF8M Wedge Gate Valve, API 600, 4 IN, 600 LB

Key Specifications / Features

Model no. : 1821088

We are a premier manufacturer in China of 4-inch gate valves designed to meet API 600 standards. Crafted from ASTM A351 CF8M stainless steel, these valves offer superior durability and corrosion resistance. With a pressure rating of 600 LB and PN100, and a nominal diameter of DN100, our valves are built to perform reliably under high-pressure conditions. They feature an OS&Y (Outside Stem and Yoke) design for easy operation, RF flanged connections for secure sealing, and a pressure seal bonnet (PSB) for enhanced performance. Operated by handwheel, these valves are ideal for a variety of demanding industrial applications.

Detail Information

Pressure Seal Bonnet Gate Valve, API 600, ASTM A351 CF8M Body, 4 Inch/DN100, 600 LB, RF Flanged.

Valve Description

1821088 Gate Valve
Design Standard: API 600
Body Material: ASTM A351 CF8M, ASTM A890 4A, ASTM A216 WCB, ASTM A890 5A, ASTM A351 CF8, ASTM A352 LCB, ASTM B148 C95800.
Nominal Size: 4 Inch, DN100
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Class: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Working Temperature: -29°C - +400°C
