ASTM A351 CF8M Swing Check Valve, BS 1868, 6 IN, 600 LB, RF

Key Specifications / Features

Model no. : 6S6RCF8M12

Looking for a swing check valve? Our stainless steel ASTM A351 CF8M body valve is the perfect solution. With BS 1868 and API 594 compliance, DN150 size, 6-inch diameter, Class 600 LB rating, RF connection, bolted bonnet, and trim 12, our valve is sure to meet your needs. Order now!

Detail Information

Stainless Steel CF8M Swing Check Valve, BS 1868, 6 inch, 600 LB, RF, CF8M body, Trim 12.

Valve Description:
Swing Check Valve
Design Standard: API 594, BS 1868
Structure: Bolted Bonnet
Nominal size: 6 Inch
Nominal class: 600 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: /
Body Material: ASTM A351 CF8M
Trim Material: ASTM A351 CF8M+STL.6
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Swing Disc, Renewable Seat

Product Range:
Body material: Stainless Steel, Alloy Steel
Normal diameter: 2 - 32 Inch (DN50 - DN800)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -46℃ - +425℃
Operation: /

CF8M Swing Check Valve
