ASTM A351 CF8M Gate Valve, OS&Y, API 600, 14 IN, CL 900 LB

Key Specifications / Features

Model no. : 1821114

As a trusted exporter of stainless steel gate valves from China, we offer premium valves designed to meet API 600 standards. Made from durable ASTM A351 CF8M stainless steel, our 14-inch gate valves are rated for 900 LB and PN150 pressure. Featuring an OS&Y configuration, RTJ flanged ends, and available with either handwheel or gear operation, these valves deliver reliable performance in high-pressure environments. Their robust design ensures durability and optimal sealing, making them an excellent choice for a wide range of industrial applications.

Detail Information

Flexible Wedge Gate Valve, ASTM A351 CF8M Body, OS&Y, 14 Inch/DN350, 900 LB, RTJ Flanged.

Valve Description

1821114 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Bore Type: Standard Bore(API 600)
Body Material: ASTM A351 CF8M, ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A352 LCB, ASTM A351 CF8, ASTM A890 5A
Nominal Size: 14 Inch, DN350
Nominal Class: 900 LB, PN150
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
Face to Face: ASME B16.10
Operation: Handwheel/Gear
Test and Inspection: API 598
End Connection: RTJ Flanged

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Design Standards: API 600, API 602, API 603, BS5352, ASME B16.34, AWWA, DIN
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld).
