ASTM A351 CF8M Gate Valve, BB, OS&Y, 12 IN, CL600, API 600

Key Specifications / Features

Model no. : 1821092

We are a leading manufacturer from China of pressure seal bonnet gate valves designed to meet API 600 standards. Our valves, crafted from ASTM A351 CF8M stainless steel, come in a 12-inch (DN300) size with a 600 LB pressure rating. Featuring a flexible wedge and OS&Y (Outside Stem and Yoke) design, these valves ensure reliable sealing and smooth operation. The bolted bonnet allows for easy maintenance, while RF flanged ends provide secure connections. Ideal for high-pressure applications, our gate valves combine durability and precision for superior performance in demanding environments.

Detail Information

API 600 Gate Valve, OS&Y, ASTM A351 CF8M Body, 12 Inch/DN300, 600 LB, RF Flanged.

Valve Description

1821092 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8M, ASTM A352 LCB, ASTM A351 CF8, ASTM B148 C95800, ASTM A216 WCB, ASTM A890 4A, ASTM A890 5A.
Nominal Size: 12 Inch, DN300
Nominal Class: Class 600 LB, PN100
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: RF Flanged
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Bore Type: Standard Bore(API 600)
Operation: Handwheel/Gear

Key Features

1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.
Design Standards: API 600, API 602, API 603, BS 5352, ASME B16.34, AWWA, DIN.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF, RTJ, BW
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
