ASTM A351 CF8M Gate Valve, API 600, 36 Inch, CL 150, OS&Y

Name: ASTM A351 CF8M Gate Valve, API 600, 36 Inch, CL 150, OS&Y
SKU: 1821060
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : 1821060

As a leading API 600 gate valve factory in China, we specialize in manufacturing high-performance valves. Our 36-inch (DN900) gate valve features a durable stainless steel ASTM A351 CF8M body, offering excellent corrosion resistance. Designed with an OS&Y mechanism and a flexible wedge, this valve ensures reliable operation in demanding applications. With a Class 150 LB rating and raised face (RF) flanged ends, it is built for optimal sealing and performance. Trust us for top-quality industrial valves designed to meet international standards.

Request a quote

Tags:

ASTM A351 CF8M Gate Valve

API 600 Gate Valve

36 Inch Gate Valve

Detail Information

API 600 Gate Valve, Flexible Wedge, 36 Inch/DN900, 150 LB, A351 CF8M Body, OS&Y, Bolted Bonnet.

Valve Description

1821060 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8M, ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800
Nominal Size: 36 Inch, DN900
Nominal Class: Class 150 LB, PN10
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material:	Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter:	2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range:	Class 150 LB - 2500 LB
Working Temperature:	-29°C - +400°C
Operation:	Handwheel/Gear/Motor
End Connections:	RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
