ASTM A351 CF8M Butterfly Valve, CL300, 3 IN, EN 593, Lug

Key Specifications / Features

Model no. : 1862350

As a stainless steel butterfly valve factory, we specialize in double eccentric, double offset valves built to API 609 Category B standards. Our 3-inch valves, made from ASTM A351 CF8M stainless steel, are rated for Class 300 LB and feature a corrosion-resistant Monel K500 stem. Bosseal valves offer key advantages, including zero leakage, low torque operation, long service life, and low emissions. Designed for bi-directional flow and equipped with fire-safe features, these valves ensure reliable performance in demanding industrial applications.

Detail Information

API 609 Double Offset Butterfly Valve, 3 Inch/DN80, 300 LB, Lever Operation.

Valve Description

1862350 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Nominal Size: 3 Inch, DN80
Nominal Class: Class 300 LB, PN50
Body Material: ASTM A351 CF8M, ASTM B148 C95800, ASTM A351 CF8, ASTM A216 WCB, ASTM A890 5A, ASTM A890 4A, Titanium.
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Lever
Seat: RPTFE, PPL
Structure: Double Offset, Double Eccentric
End Connection: Lug
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.


Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2  - 48 Inches (DN15 - DN1200)
Pressure Range: CL 150, 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
