ASTM A351 CF8 Wedge Gate Valve, 32 Inch, 600 LB, RF Flanged

Key Specifications / Features

Model no. : 1821101

We offer RF flanged gate valves crafted from ASTM A351 CF8 stainless steel. Our 32-inch (DN800) valves adhere to API 600 standards and are designed for high performance with a Class 600 LB and PN100 rating. Featuring a flexible wedge and a pressure seal bonnet, these valves ensure reliable sealing and durability under high-pressure conditions. Engineered for precision and efficiency, our gate valves are ideal for demanding industrial applications, providing superior flow control and long-lasting reliability. As a leading gate valve manufacturer in China, we are committed to delivering top-quality products to meet your needs.

Detail Information

32 Inch Gate Valve, ASTM A351 CF8 Body, DN800, Class 600 LB, PSB, OS&Y, RF Flanged.

Valve Description

1821101 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8, ASTM A890 4A, ASTM A351 CF8M, ASTM A352 LCB, ASTM A216 WCB, ASTM A890 5A, ASTM B148 C95800.
Nominal Size: 32 Inch, DN800
Nominal Class: Class 600 LB, PN100
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55
Operation: Handwheel/Gear
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Operation: Handwheel/Gear/Motor
Working Temperature: -29°C - +400°C
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Seat Types: Metal Seat Gate Valve(hard faced), Resilient Gate Valve(rubber seat) Bonnet
Bonnet Types: Bolted Bonnet, Pressure Bonnet, Welded Bonnet, Bellow Seal

Bolted Bonnet Gate Valve
Bolted Bonnet Gate Valve


Pressure Seal Bonnet Gate Valve
Pressure Seal Bonnet Gate Valve
