ASTM A351 CF8 Gate Valve, API 600, 32 Inch, CL 300, OS&Y

Key Specifications / Features

Model no. : 1821080

As a leading API 600 gate valve factory in China, we offer premium valves with a stainless steel ASTM A351 CF8 body. Our 32-inch (DN800) gate valves feature an OS&Y design and flexible wedge for reliable sealing and performance. With a Class 300 LB pressure rating and RF flanged ends, these valves are engineered for durability and ease of installation in demanding applications. Trust our valves for their superior quality and robust construction, ensuring long-lasting operation and efficiency in industrial environments.

Detail Information

API 600 Gate Valve, Flexible Wedge, 32 Inch/DN800, 300 LB, A351 CF8 Body, OS&Y, Bolted Bonnet.

Valve Description

1821080 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8, ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800
Nominal Size: 32 Inch, DN800
Nominal Class: Class 300 LB, PN50
Bore Type: Standard Bore(API 600)
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back Seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
