API 600
Gate Valve, ASTM A216 WCB Body, Trim 8, 28 Inch/DN700, 150 LB, RF Flanged.
Valve Description
1821057 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A351 CF8, ASTM B148 C95800, ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A.
Nominal Size: 28 Inch, DN700
Nominal Class: Class 150 LB, PN16
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: RF Flanged
Bore Type: Standard Bore(API 600)
Key Features
1. OS&Y (Outside Screw and Yoke) design for reliable operation.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.
Product Range
| Body Material: |
Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze |
| Normal Diameter: |
2 Inch - 64 Inch (DN50 - DN1600) |
| Pressure Range: |
Class 150 LB - 2500 LB |
| End Connections: |
RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld) |
| Working Temperature: |
-29°C - +400°C |
| Operation: |
Handwheel/Gear/Motor |
