ASTM A216 WCB Flanged Butterfly Valves, API 609, 42IN, CL150

Key Specifications / Features

Model no. : 1862262

As a leading API 609 butterfly valve provider in China, we offer high-quality valves built to EN 593 standards. Our 42-inch, 150-lb valve features a durable ASTM A216 WCB body with a double eccentric design, ensuring reliable performance in demanding applications. Equipped with an RPTFE seat and a 17-4PH stainless steel stem, this valve provides excellent corrosion resistance and durability. The flanged ends and gear operation make it easy to install and operate, making it ideal for isolation and regulating applications in pipelines. Built for longevity, this valve ensures optimal performance.

Detail Information

Double Eccentric Butterfly Valve, 42 Inch/DN1050, 150 LB, A216 WCB Body, Double Flanged Ends.

Valve Description

1862262 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Body Material: ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, ASTM A351 CF8M, Titanium, ASTM A890 4A, ASTM B148 C95800.
Nominal Size: 42 Inch, DN1050
Structure: Double Offset, Double Eccentric
Nominal Class: 300 LBS, PN50
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
