ASTM A216 WCB Butterfly Valve, 2 IN, 300 LB, EN 593, Wafer

Key Specifications / Features

Model no. : 1862054

As a trusted carbon steel butterfly valve supplier from China, we offer 2-inch (DN50) double eccentric butterfly valves designed to EN 593 and API 609 standards. With a 300 LB pressure rating, these valves feature a durable 17-4PH stem and a soft RPTFE seat for reliable tight sealing performance. The wafer end design ensures easy installation, and a fire-safe seat option is available for enhanced safety in critical applications. These valves provide dependable operation and are ideal for industries requiring both high performance and durability.

Detail Information

API 609 High-Performance Butterfly Valve, Double Eccentric, 2 Inch/DN50, 300 LB, RPTFE Seat, Wafer Ends.

Valve Description

1862054 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 2 Inch, DN50
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Lever
Body Material: ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
