Key Specifications / Features
As a trusted provider of 2 Inch Y Pattern Globe Valves in China, we offer a high-quality valve that meets rigorous industry standards, including ASTM A182 F22, ASME B16.34, and API 602. Constructed from durable stainless steel, this valve is rated for Class 1690 LB pressure and is designed for optimal performance in demanding applications. With a DN50 size, it features a Y pattern design that reduces pressure drop and enhances flow control, making it ideal for efficient fluid management. The valve includes a bolted bonnet for secure sealing and easy maintenance, and comes with Socket Weld (SW) ends for robust connections. Engineered for reliability and precision, our Y Pattern Globe Valve is perfect for applications requiring high-pressure regulation and superior flow control.
Detail Information
ASME B16.34 Y Globe Valve, Class 1690 LB, 2 Inch, Bolted Bonnet, ASTM A182 F22 Body, SW End.
Valve Description:
1852049 Globe Valve
Design Standard: ASME B16.34, API 602
Structure: Bolted Bonnet, Bonnetless, Welded Bonnet, Pressure Seal Bonnet
Nominal Size: 2 Inch/DN50
Nominal Class: Class 1690 LB
Bore Type: Reduced
Face to Face: MFG'S
Operation: Handwheel
Body Material: ASTM A182 F11, ASTM A182 F91, ASTM A182 F316, ASTM A105N, ASTM A182 F22
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Test and Inspection: API 598
End Connection: BW, SW, NPT
Applications: Water Treatment Plants, Chemical Processing, Power Generation, HVAC Systems, Oil and Gas Industry.
Key Features:
1. Rising Stem with Handwheel for Precise Operation
2. Options: Swivel, Plug, or Needle Disc for Versatile Applications
3. Y-Pattern Design for Efficient Flow Control
4. Outside Screw & Yoke (OS&Y) for Enhanced Durability
5. Live Load Packing for Reliable Sealing
6. Backseat Feature for Additional Leak Prevention
7. Compact, Robust Construction Ideal for High-Temperature and High-Pressure Environments.
Product Portfolio:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 LB - 4500 LB
Working Temperature: -29°C to +525°C
Operation: Manual or Actuated
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
