ASME B16.34 Reduced Bore Ball Valve, ASTM B148 C95800, 12 IN

Name: ASME B16.34 Reduced Bore Ball Valve, ASTM B148 C95800, 12 IN
SKU: bv-20250322-09
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : BV-20250322-09

As a leading ball valve factory in China, we manufacture high-performance reduced-bore ball valves designed to ASME B16.34 standards. Our 12-inch (DN300), Class 300 LB valves feature a durable aluminum bronze ASTM B148 C95800 body, ensuring excellent corrosion resistance and reliability. Equipped with gear operation for precise control, these valves provide smooth and efficient performance in demanding applications. With RF flanged ends for secure installation, they are ideal for marine, offshore, and industrial environments. Engineered for durability and efficiency, our ball valves offer long-lasting and dependable flow control.

Request a quote

Tags:

ASME B16.34 Ball Valve

Reduced Bore Ball Valve

Aluminum bronze Ball Valve

Detail Information

Valve Description:
187301029 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 12 Inch, DN300
Nominal Class: 300 LB
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block&Bleed(DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission(Optional), DIB (Optional), Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: RF, FF
Working Temperature: -26°C to +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
