API 6D Trunnion Mounted Ball Valves, A350 LF2, 3 IN, 2500 LB

Key Specifications / Features

Model no. : 1811178

We are a leading manufacturer of 3-inch trunnion ball valves from China, designed to meet API 6D and BS 5351 standards. Crafted from durable carbon steel ASTM A350 LF2, these valves are engineered for high-pressure applications, rated at 2500 LB. They feature a bolted bonnet for secure assembly, a soft seat for reliable sealing, and RTJ flanged ends for enhanced performance in demanding environments. Our trunnion ball valves ensure optimal flow control and are ideal for various industrial applications requiring robust and efficient valve solutions.

Detail Information

ASTM A350 LF2 Trunnion Ball Valve, 3 Inch/DN80, Class 2500 LB, RTJ Flanged.

Valve Description

1811178 Trunnion Mounted Ball Valve
Design Standard: API 6D, BS 5351
Structure: 3pcs body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 3 Inch, DN80
Nominal Class: 2500 LB, PN420
Bore Type: Full Bore or Reduced Bore
Operation: Lever/Gear
Body Material: ASTM A105N or ASTM A350 LF2
End Connection: RTJ Flanged
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55, ASTM A105+ENP, ASTM A350 LF2+ENP
Seat Insert: RPTFE, DEVLON, NYLON, PEEK
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-static Device, Fire-Safe Design, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission (Optional), DIB (Optional).

Product Range

Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
Working temperature: -26°C - +150°C
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End connection: RF, RTJ, BW, HUB
