API 6D Swing Check Valve, ANSI 300, 18 IN, ASTM A351 CF8, RF

Key Specifications / Features

Model no. : 1841051

The 1841051 Swing Check Valve is robust and reliable, designed for diverse commercial and industrial applications. Featuring a high-performance bolted bonnet and optional gear operation, it ensures durable performance. Constructed with Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A216 WCB, ASTM A352 LCB, and ASTM A995 4A, 5A materials, this valve maintains flow control, regulates pressure in liquid filling lines, and manages temperatures in heat exchangers with steam feed lines. Compliant with ASME B16.10 and API 598 standards, it's available in 18-inch size, 300 LB class, with RF flanged end connections. Bore options include full bore (API 6D) or standard bore (BS 1868, API 594), catering to various application needs.

Detail Information

API 6D Swing Check Valve, 18 Inch, Class 300 LB, Stainless Steel, ASTM A351 CF8, Full Opening.

Valve Description

1841051 Swing Check Valve
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Gear Design Available
Design Standard: API 6D, BS 1868, API 594
Nominal Size: 18 Inch
Nominal Class: 300 LB
Body Material: Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Structure: Bolted Bonnet
Operation: Gear
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
Face to Face: ASME B16.10
Test and Inspection: API 598
End Connection: Flanged RF

Product Offering /
Body Materials Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-bronze
Normal Diameter 1/2-48 Inch (DN15-DN1200)
Pressure Range 150-2500 LB
End Connections Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW)
Operation Not Applicable (Manual or actuated available for special request)
Working Temperature -196°C to +450°C
