API 6D Swing Check Valve, 2 IN, ANSI 300, ASTM A351 CF8, RF

Key Specifications / Features

Model no. : 1841041

Introducing our high-performance API 6D Swing Check Valve, fabricated in China with precision and expertise. Crafted from premium stainless steel ASTM A351 CF8, this valve ensures superior corrosion resistance and durability. Designed for a 2-inch size and Class 300 LB, it meets stringent BS 1868 and API 594 standards for reliable performance. The valve features a robust lever-operated mechanism and RF flanged ends for easy installation and maintenance. Ideal for various industrial applications, our swing check valve guarantees exceptional functionality and long-lasting service. Choose our API 6D Swing Check Valve for top-tier quality and dependability.


Detail Information

API 6D Swing Check Valve, 2 Inch, Class 300 LB, Stainless Steel, ASTM A351 CF8, Full Opening.

Valve Description 1841041 Swing Check Valve
Key Features Full Opening Design Available, Bolted Bonnet, Operation Lever Design Available
Design Standard API 6D, BS 1868, API 594
Nominal Size 2 Inch
Nominal Class 300 LB
Body Material Stainless Steel, ASTM A351 CF8, CF8M, C95800 Alloy, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A.
Trim Material ASTM A182 F6A, F304, F316, F51, F53, F55
Structure Bolted Bonnet
Operation Lever
Bore Type Standard Bore(BS 1868, API 594), Full Bore(API 6D)
Face to Face ASME B16.10
Test and Inspection API 598
End Connection Flanged RF


Product Offering

Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-bronze
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: 150-2500 LB
Operation: Not Applicable (Manual or actuated available for special request)
Working Temperature: -196°C to +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
