API 6D Soft Seat Ball Valves, Aluminum Bronze C95800, 26 IN

Key Specifications / Features

Model no. : BV-187301014

As a trusted provider of soft seat ball valves, we manufacture high-performance valves designed to API 6D and BS 5351 standards. Our 26-inch (DN650) ball valve features a durable ASTM B148 C95800 aluminum bronze body and trim, offering excellent corrosion resistance in marine and industrial environments. With a reduced bore design, it ensures efficient flow control while maintaining reliability. Rated for Class 150 LB, it comes with raised face (RF) flanged ends for secure installation. Built for durability and smooth operation, our soft seat ball valves deliver superior performance.

Detail Information

Valve Description:
187301014 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 26 Inch, DN650
Nominal Class: 150 LB
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-Static Device, Fire-Safe Design, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission (Optional), Double Isolation & Bleed (DIB) (Optional), and Corrosion-Resistant Aluminum Bronze for Seawater Applications.

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Raised Face (RF), Flat Face (FF)
