API 609 Wafer Butterfly Valve, EN 593, A890 5A, CL300, 10 IN

Name: API 609 Wafer Butterfly Valve, EN 593, A890 5A, CL300, 10 IN
SKU: 1862186
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Model no. : 1862186

As a trusted supplier of duplex stainless steel butterfly valves, we offer high-performance valves designed to meet EN 593 and API 609 Category B standards. Our 10-inch (DN250) valve features a double eccentric design for enhanced durability and precise control, while the soft seat ensures reliable sealing. Rated at 300 LB, it is equipped with a robust 17-4PH stainless steel stem for added strength and corrosion resistance. The wafer end connection allows for easy installation, making it ideal for a variety of industrial applications requiring dependable performance.

Request a quote

Tags:

ASTM A890 5A Butterfly Valve

10 Inch Butterfly Valve

Class 300 LB Butterfly Valve

Detail Information

Double Eccentric High-Performance Butterfly Valve, ASTM A890 5A Body, 10 Inch/DN250, 300 LB, RPTFE Seat.

Valve Description

1862186 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Nominal Size: 10 Inch, DN250
Nominal Class: Class 300 LB, PN50
Body Material: ASTM A890 5A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A351 CF8, Titanium.
Seat Type: Soft Seat
Operation: Gear
Structure: Double Offset, Double Eccentric
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium.

Key Features

1. Long lifespan for high-frequency operation (up to a million cycles).
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: CL 150-300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
