API 609 Titanium Lugged Butterfly Valves, CL150, 10 IN

Key Specifications / Features

Model no. : 1862333

As a leading manufacturer of 10-inch lug butterfly valves in China, we specialize in API 609 Category B and EN 593 compliant designs. Our DN250 valves feature a double offset and double eccentric configuration, constructed from durable titanium and rated for Class 150 LB. Equipped with a Monel K500 stem, these valves offer excellent performance and longevity. We ensure our products adhere to the highest industry standards, providing reliable solutions for a wide range of applications.

Detail Information

RPTFE Seated Butterfly Valve, Double Offset, 10 Inch, Class 150 LB, Double Offset.

Valve Description

1862333 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Structure: Double Offset, Double Eccentric
Body Material: Titanium Alloy, ASTM A351 CF8M, ASTM A216 WCB, ASTM A351 CF8, ASTM B148 C95800, ASTM A890 5A, ASTM A890 4A.
Nominal Size: 10 Inch, DN250
Nominal Class: Class 150 LB, PN20
Seat Type: Soft Seat
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 5A, ASTM A351 CF8M, ASTM A890 4A, ASTM A351 CF8, ASTM B148 C95800, Titanium
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Lug
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2 - 48 Inches (DN15 - DN1200)
Pressure Range: Class 150 - 300 LBS
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Seat Type: PTFE, RPTFE, PPL(for higher temperature), RPTF
