API 609 Titanium Butterfly Valve, RPTFE Seated, CL150, 24 IN

Key Specifications / Features

Model no. : 1862213

We manufacture 24-inch double offset butterfly valves featuring a titanium body, designed to meet API 609 B and EN 593 standards. These valves are equipped with a 17-4PH stainless steel stem and a double eccentric design for enhanced performance. Rated at Class 150 LB, they feature lug type ends for secure installation and reliable operation. Engineered for durability and efficiency, our valves provide exceptional sealing and performance in demanding applications.

Detail Information

RPTFE Seated Butterfly Valve, Double Offset, 24 Inch/DN600, Class 150 LB, Gear Operation.

Valve Description

1862213 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Structure: Double Offset, Double Eccentric
Body Material: Titanium, ASTM A890 5A, ASTM A351 CF8M, ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A351 CF8.
Nominal Size: 24 Inch, DN600
Nominal Class: Class 150 LB, PN16
Seat Type: Soft Seat
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8M, ASTM A890 4A, ASTM A351 CF8, ASTM A890 5A, ASTM B148 C95800, Titanium
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Lug
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2 - 48 Inches (DN15 - DN1200)
Pressure Range: Class 150 - 300 LBs
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Seat Type: PTFE, RPTFE, PPL(for higher temperature), RPTF
