Key Specifications / Features
Model no. : BTV-187302032
We are a reliable supplier of high-performance butterfly valves built to meet API 609 Category B standards. Engineered with a durable aluminum bronze ASTM B148 C95800 body, these valves are designed for demanding applications. The 18-inch size and Class 300 LB pressure rating ensure optimal flow control in high-pressure environments. Featuring a double offset design and flanged ends, our valves provide tight sealing, reduced wear, and extended service life. Ideal for marine, offshore, and industrial systems requiring corrosion resistance and reliable performance under harsh conditions.
Valve Description:
187302032 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Structure: Double Offset, Double Eccentric
Nominal Size: 18 Inch, DN450
Nominal Class: 300 LB, PN50
Seat Type: Soft Seat
End Connection: Wafer/Lug/Flanged
Operation: Lever/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation(million cycling), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available, Aluminium bronze for sea water service
Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
