API 609 Double Offset Butterfly Valve, Titanium, CL 300, 30IN

Key Specifications / Features

Model no. : 1862195

We produce titanium wafer butterfly valves engineered for high performance. Featuring a double offset design that meets API 609 and EN 593 standards, our valves provide precise control and reliability. At 30 inches (DN750), they are rated for 300 LB and PN50 pressure, equipped with a soft seat for optimal sealing. Ideal for isolation and regulating applications, these valves perform exceptionally well in pipelines requiring frequent open and close operations. Designed for durability and efficiency, they excel in demanding industrial environments. As a leading butterfly valve manufacturer in China, we ensure top-quality products for your needs.

Detail Information

API 609 High-Performance Butterfly Valves, Titanium Body, 30 Inch/DN750, 300 LB, Wafer Ends.

Valve Description

1862195 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Nominal Size: 30 Inch, DN750
Nominal Class: Class 300 LB, PN50
Body Material: Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A351 CF8M, ASTM A351 CF8, ASTM A890 4A, ASTM B148 C95800.
Seat Type: Soft Seat
Structure: Double Offset, Double Eccentric
End Connection: Wafer
Operation: Gear
Seat: RPTFE, PPL
Test and Inspection: API 598, API 609
Face to Face: API 609, EN 593
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 - 300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
