Key Specifications / Features
As a leading manufacturer of lug butterfly valves, we produce high-performance valves with a double-offset design, built to EN 593 and API 609 Category B standards. Made from ASTM A890 5A, these 24-inch (DN600), Class 150 LB valves feature an RPTFE seat and a durable Monel K500 stem. Compared to other valve types, our butterfly valves offer significant cost and space savings, a wider size range, faster operation, and reduced wear on the disc and seat sealing surface, making them ideal for efficient, long-term use in various applications.
High-Performance
Butterfly Valve, 24 Inch/DN600, 150 LB, Double Offset, Gear Operation.
Valve Description
| 1862339 High-Performance Butterfly Valve |
| Design Standard: |
EN 593, API 609 Category B |
| Structure: |
Double Offset, Double Eccentric |
| Nominal Size: |
24 Inch, DN600 |
| Nominal Class: |
Class 150 LB, PN16 |
| Seat Type: |
Soft Seat |
| Operation: |
Gear |
| Body Material: |
ASTM A890 5A, ASTM B148 C95800, ASTM A890 4A, Titanium, ASTM A351 CF8, ASTM A351 CF8M, ASTM A216 WCB. |
| Seat: |
RPTFE, PPL |
| End Connection: |
Lug |
| Face to Face: |
API 609, EN 593 |
| Test and Inspection: |
API 598, API 609 |
| Trim Material: |
ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium |
| Key Features: |
Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available. |
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2-48 Inch (DN15-DN1200)
Pressure Range: Class 150-300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
