API 609 Double Offset Butterfly Valve, 5A, 36 IN, CL 300

Key Specifications / Features

Model no. : 1862155

We manufacture high-performance butterfly valves from ASTM A890 5A duplex stainless steel. Our 36-inch double offset butterfly valves are designed to meet API 609 Category B and EN 593 standards, offering exceptional durability and reliability. Rated at Class 300 LB, these valves feature a soft seat for optimal sealing performance in demanding applications. Engineered for strength and efficiency, our butterfly valves are built to provide long-lasting service across various industrial environments. As a leading butterfly valve manufacturer in China, we are committed to delivering top-quality solutions.

Detail Information

High-Performance Butterfly Valves, ASTM A890 5A Body, 36 Inch/DN900, 300 LB, Double Flanged.

Valve Description

1862155 High-Performance Butterfly Valve
Design Standard: API 609 Category B, EN 593
Nominal Size: 36 Inch, DN900
Nominal Class: Class 300 LB, PN50
Body Material: ASTM A890 5A, Titanium, ASTM A216 WCB, ASTM A351 CF8M, ASTM A351 CF8, ASTM A890 4A, ASTM B148 C95800.
Seat Type: Soft Seat
Structure: Double Offset, Double Eccentric
End Connection: Double Flanged
Operation: Gear
Seat: RPTFE, PPL
Face to Face: API 609, EN 593
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2 - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 - 300 LB
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C - +120°C (180°C for PPL seat)
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
