API 609 Category B Titanium Butterfly Valve, CL300, 14 IN

Key Specifications / Features

Model no. : 1862356

As a trusted supplier of EN 593 lug butterfly valves, we offer valves designed to meet API 609 Category B standards with a double offset configuration. Featuring a durable Monel K500 stem and titanium alloy body, our 14-inch valves are rated for Class 300 LB and equipped with a soft RPTFE seat for optimal sealing performance. These valves provide excellent corrosion resistance, low torque operation, and long-term reliability, making them ideal for use in demanding industrial environments.

Detail Information

API 609 Double Offset Butterfly Valve, 14 Inch/DN350, CL 300 LB, RPTFE Seat.

Valve Description

1862356 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 14 Inch, DN350
Nominal Class: Class 300 LB, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: Titanium Alloy, ASTM B148 C95800, ASTM A216 WCB, ASTM A890 5A, ASTM A351 CF8M, ASTM A351 CF8, ASTM A890 4A.
Seat: RPTFE, PPL
End Connection: Lug
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: Titanium, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium.
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: CL 150 LB - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged(FF, RF, RTJ)
Top Mounting: ISO 5211 Top Mounting Available
Operation Types: Lever, Gear, Pneumatic Actuator
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
