Key Specifications / Features
Model no. : BTV-187302042
We are a reputable manufacturer of aluminum bronze butterfly valves built to API 609 Category B standards for high-performance applications. Constructed with a robust ASTM B148 C95800 body and disc, these 48-inch valves are rated for Class 300 LB and designed to handle demanding pressure and corrosion challenges. Featuring flanged end connections for secure and stable installation, each valve offers the choice of lever or gear operation for precise and reliable flow control. Ideal for use in marine, offshore, and industrial environments requiring strength, durability, and long-lasting performance.
Valve Description:
187302042 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Structure: Double Offset, Double Eccentric
Nominal Size: 48 Inch
Nominal Class: Class 300 LB
Seat Type: Soft Seat
End Connection: Wafer/Lug/Flanged
Operation: Lever/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation(million cycling), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available, Aluminium bronze for sea water service
Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
