Key Specifications / Features
Model no. : BTV-187302022
We are a trusted aluminum bronze butterfly valve supplier, offering high-performance valves designed to API 609 Category B standards. This 2-inch (DN50) valve features a durable ASTM B148 C95800 body, ideal for corrosive and seawater environments. Rated for Class 300 LB and PN50 pressure, it is available in wafer, lug, or flanged end connections to suit various piping systems. The valve is equipped with an RPTFE or PPL seat, providing excellent sealing performance and chemical resistance. A reliable solution for marine, offshore, and industrial fluid control applications.
Valve Description:
187302022 High Performance Butterfly Valve
Design Standard: API 609 Category B, BS EN 593
Structure: Double Offset, Double Eccentric
Nominal Size: 2 Inch, DN50
Nominal Class: 300 LB, PN50
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Seat Type: Soft Seat
End Connection: Wafer/Lug/Flanged
Operation: Lever/Gear
Seat: RPTFE, PPL
Face to Face: API 609, BS EN 593
Test and Inspection: API 598, API 609
Key Features: Long working life for frequent operation(million cycling), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available, Aluminium bronze for sea water service
Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: Wafer/Lug/Flanged
Working Temperature: -26°C - +120°C (180°C for PPL Seat)
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
