API 600 Gate Valve, 30 IN, 150 LB, ASTM A352 LCB, RF Flanged

Key Specifications / Features

Model no. : 1821058

As a leading gate valve manufacturer from China, we provide high-performance flexible wedge gate valves built to API 600 standards. Made from ASTM A352 LCB, our 30-inch (DN750) valves are rated for Class 150 LB. Designed with an Outside Screw & Yoke (OS&Y) and a bolted bonnet for easy maintenance, they also feature a screwed-in back seat for enhanced reliability. These robust valves are engineered for demanding applications, ensuring durability, safety, and long-lasting performance in various industrial sectors. Trust us for dependable valve solutions tailored to your needs.

Detail Information

ASTM A216 WCB Gate Valve, Flexible Wedge, API 600, 30 Inch/DN750, 150 LB, Handwheel/Gear Operation.

Valve Description

1821058 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A352 LCB, ASTM A216 WCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, 5A, ASTM B148 C95800.
Nominal Size: 30 Inch, DN750
Nominal Class: 150 LB, PN10
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, F51, F53, F55.
Face to Face: ASME B16.10
Bore Type: Standard Bore(API 600)
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design.
2. Screwed-in back seat for added security.
3. Rising stem with the non-rising handwheel.
4. Flexible wedge for improved sealing.
5. Low emission design for environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 - 64 Inch (DN50 - DN1600)
Pressure Range: 150 - 2500 LB
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
