API 600 Gate Valve, 26 IN, 600 LB, ASTM A890 5A, OS&Y, BB

Key Specifications / Features

Model no. : 1821098

We offer high-quality flexible wedge gate valves built to API 600 standards. Crafted from durable ASTM A890 5A material, our 26-inch (DN650) gate valves are designed for demanding applications. These Class 600 LB valves feature an OS&Y construction, bolted bonnet, and a screwed-in back seat, ensuring secure performance and extended service life. Engineered for efficiency and reliability, our gate valves deliver optimal flow control in high-pressure environments, making them ideal for a wide range of industrial uses.

Detail Information

ASTM A890 5A Flexible Wedge Gate Valve, API 600, 26 Inch/DN650, 600 LB, Handwheel/Gear Operation.

Valve Description

1821098 Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Body Material: ASTM A890 5A, ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM B148 C95800.
Nominal Size: 26 Inch, DN650
Nominal Class: 600 LB, PN100
End Connection: RF Flanged
Operation: Handwheel/Gear
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55.
Face to Face: ASME B16.10
Bore Type: Standard Bore(API 600)
Test and Inspection: API 598

Key Features

1. OS&Y (Outside Screw and Yoke) design.
2. Screwed-in back seat for added security.
3. Rising stem with the non-rising handwheel.
4. Flexible wedge for improved sealing.
5. Low emission design for environmental compliance.

Product Range

Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze
Normal Diameter: 2 - 64 Inch (DN50 - DN1600)
Pressure Range: 150 - 2500 LB
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld)
Material Types: Steel Gate Valve(cast and forged), Iron Gate Valve
Seat Types: Metal Seat Gate Valve(hard faced), Resilient Gate Valve(rubber seat) Bonnet
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
