Key Specifications / Features
Introducing our API 594 Swing Check Valve, designed for optimal performance and durability. Manufactured with a robust bolted bonnet and constructed from ASTM A351 CF8M stainless steel, this valve ensures reliable service in demanding environments. Featuring Trim 12 and RF flanged ends, it is engineered to provide a secure and efficient flow control solution. The 4-inch size and Class 150 LB rating make it suitable for a variety of industrial applications. With lever operation for ease of use, this swing check valve is the ideal choice for preventing backflow and maintaining system integrity. Trust in our quality craftsmanship for your fluid management needs.
Detail Information
API 594 Swing Check Valve, Class 150 LB, Lever Operation, 2 Inch, Bolted Bonnet, RF, CF8M Body with Trim 12
Valve Descriptions
1841023 Swing Check Valve
Design Standard: API 594, API 6D, BS 1868
Structure: Bolted Bonnet
Nominal Size: 4 Inch
Nominal Class: 150 LB
Bore Type: Full Standard Bore(BS 1868, API 594) or Bore(API 6D)
Operation: Lever
Body Material: ASTM A351 CF8M, ASTM A216 WCB, CF8, ASTM A352 LCB, 4A, 5A, C95800 Alloy.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Lever design Available
End Connection: RF Flanged
Product Selection
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze
Normal diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Raised Face, Ring-Type Joint, Butt Weld
