Key Specifications / Features
The 1841078 Swing Check Valve is crafted to meet API 594, API 6D, and BS 1868 standards, ensuring robust performance in industrial applications. This Class 600 LB valve boasts a substantial 32-inch nominal size with a bolted bonnet and RF flanged end connection for straightforward installation. Engineered from durable ASTM A351 CF8M material and featuring Trim 12 options, it offers reliability and longevity. The valve supports both full standard bore (BS 1868, API 594) and bore (API 6D) configurations, with gear operation and optional lever design enhancing versatility. Tested to API 598 standards, it meets ASME B16.10 face-to-face dimensions, making it ideal for critical environments.
API 594 Swing Check Valve, Class 600 LB, Gear Operation, 32 Inch, Bolted Bonnet, RF, A351 CF8M Body with Trim 12.
Valve Descriptions
1841078 Swing Check Valve
Design Standard: API 594, API 6D, BS 1868
Structure: Bolted Bonnet
Nominal Size: 32 Inch
Nominal Class: 600 LB
Bore Type: Full Standard Bore(BS 1868, API 594) or Bore(API 6D)
Operation: Gear
Body Material: ASTM A351 CF8M, CF8, ASTM A216 WCB, ASTM A352 LCB, ASTM A995 4A, 5A, C95800 Alloy.
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Bolted Bonnet, Full Opening design available, Operation Gear design Available
End Connection: RF Flanged
| Product Selection |
| Body material: |
Carbon Steel, Stainless Steel, Alloy Steel, Al-bronze |
| Normal diameter: |
1/2 Inch - 48 Inch (DN15-DN1200) |
| Pressure Range: |
Class 150 LB - 2500 LB |
| Working temperature: |
-196°C - +450°C |
| Operation: |
Not Applicable (Manual or actuated available for special request) |
| End Connections: |
Raised Face, Ring-Type Joint, Butt Weld |
