Key Specifications / Features
Model no. : BV-20250322-01
As a leading ball valve manufacturer in China, we specialize in high-quality aluminum bronze ball valves designed to meet API 6D, BS 5351, and ASME B16.34 standards. Our 48-inch, Class 150 LB ball valves feature durable ASTM B150 C63200 trim for superior performance in demanding applications. Available with RF and FF end connections, these valves ensure reliable sealing and long service life. Engineered for excellence, our aluminum bronze ball valves are ideal for marine, offshore, and industrial environments.
Valve Description:
187301021 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 48 Inch, DN1200
Nominal Class: 150 LB, PN20
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block&Bleed(DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission(Optional), DIB (Optional), Aluminium Bronze for Sea Water Service
Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: RF, FF
Working Temperature: -26°C to +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
