Key Specifications / Features

Model no. : 1841074

The 1841074 Swing Check Valve is designed to BS 1868, API 594, and API 6D standards, ensuring robust performance in industrial settings. This Class 600 LB valve features a 24-inch (DN 600) size with a bolted bonnet and flanged end connection for easy installation. Constructed from ASTM A351 CF8M, it offers durability and reliability, complemented by trim materials such as ASTM A182 F6A, F304, F316, F51, F53, and F55. The valve includes options for full opening design and gear operation, adheres to ASME B16.10 face-to-face dimensions, and is rigorously tested to API 598 standards, making it ideal for critical applications.


Detail Information

600 LB Swing Check Valve, Bolted Bonnet, 24 Inch, API 6D, Flanged, ASTM A351 CF8M, Trim 12.

Descriptions

1841074 Swing Check Valve
Design Standard: BS 1868, API 594, API 6D
Structure: Bolted Bonnet
Sizes: 24 Inch, DN600
Pressure: Class 600 LB
Body Materials: ASTM A351 CF8M, CF8, ASTM A216 WCB, ASTM B148 C95800, ASTM A352 LCB, ASTM A995 4A, 5A, Stainless Steel.
Trim Materials: ASTM A182 F6A, F304, F316, F51, F53, F55
Bore Type: Standard Bore(BS 1868, API 594), Full Bore(API 6D)
End Connection: RF Flanged
Operation: Gear
Key Features: Bolted Bonnet, Full Opening design available, Operation Gear Design Available
Face to Face: ASME B16.10
Test and Inspection: API 598


Product Line

Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Body Materials: Alloy Steel, Carbon Steel, Aluminium-bronze, Stainless Steel.
Pressure Range: Class 150 - 2500 LB
Working Temperature: -196°C - +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
