Key Specifications / Features

Model no. : 1841037

We specialize in exporting 36-inch swing check valves designed for superior performance and reliability. Constructed from ASTM A351 CF8M stainless steel, these valves feature Trim 12 for enhanced durability and efficiency. Compliant with API 594 standards, they ensure seamless integration into industrial applications. Sized at DN900 and rated for Class 150 LB pressure, our valves are ideal for demanding environments. With RF flanged ends for secure installation and an operation lever for ease of use, these valves provide precise control and reliable operation. Choose our swing check valves for robust construction and dependable performance in critical systems.


Detail Information

API 594 Swing Check Valves, Bolted Bonnet, 36 Inch/DN900, 150 LB, RF Flanged, ASTM A351 CF8M, Trim 12.


Valve Specifications


1841037 Swing Check Valve
Design Standard: API 594, API 6D, BS 1868
Body Material: ASTM A351 CF8M, CF8, ASTM A352 LCB, Stainless Steel, C95800 Alloy, ASTM A216 WCB, ASTM A995 4A, 5A.
Structure: Bolted Bonnet
Nominal Size: 36 Inch
Nominal Class: 150 LB
Trim Material: ASTM A182 F6A, F304, F316, F51, F53, F55
End Connection: RF Flanged
Bore Type: Standard Bore(BS 1868, API 594) or Full Bore(API 6D)
Operation: Lever
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Full Opening Design Available, Bolted Bonnet, Operation Lever Design Available


Product Range


Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-Bronze
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: 150 - 2500 LB
Operation: Not Applicable (Manual or actuated available for special request)
Working temperature: -196°C - +450°C
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
