Key Specifications / Features
Engineered to meet API 594, API 6D, and BS 1868 standards, this robust bolted bonnet valve ensures durability and reliability. Constructed from ASTM A351 CF8M, CF8, ASTM A352 LCB, Stainless Steel, C95800 Alloy, ASTM A216 WCB, ASTM A995 4A, 5A materials, it's designed for diverse environments.
With a 32-inch nominal size and Class 300 LB rating, it supports standard bore (BS 1868, API 594) and full bore (API 6D) configurations. Featuring RF flanged end connections and operating via gear mechanism, it meets ASME B16.10 dimensions and undergoes API 598 testing for quality assurance. Ideal for robust flow control applications.
API 594 Swing Check Valves, Bolted Bonnet, 32 Inch, 300 LB, RF Flanged, ASTM A351 CF8M, Trim 12.
| Valve Specifications |
1841057 Swing Check Valve |
| Design Standard |
API 594, API 6D, BS 1868 |
| Body Material |
ASTM A351 CF8M, CF8, ASTM A352 LCB, Stainless Steel, C95800 Alloy, ASTM A216 WCB, ASTM A995 4A, 5A. |
| Structure |
Bolted Bonnet |
| Key Features |
Full Opening Design Available, Bolted Bonnet, Operation Gear Design Available |
| Nominal Size |
32 Inch |
| Nominal Class |
300 LB |
| Trim Material |
ASTM A182 F6A, F304, F316, F51, F53, F55 |
| End Connection |
RF Flanged |
| Bore Type |
Standard Bore(BS 1868, API 594) or Full Bore(API 6D) |
| Operation |
Gear |
| Face to Face |
ASME B16.10 |
| Test and Inspection |
API 598 |
Product Range
Body Materials: Stainless Steel, Alloy Steel, Carbon Steel, Aluminum-Bronze
Normal Diameter: 1/2 - 48 Inch (DN15-DN1200)
Pressure Range: 150 - 2500 LB
Working temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW).
