2pcs Flanged Ball Valves, API 6D, B148 C95800, 18 IN, CL300

Key Specifications / Features

Model no. : BV-187301032

We are a trusted supplier of 2-piece ball valves, offering high-performance valves designed to API 6D standards. Our 18-inch (DN450) Class 300 LB (PN20) ball valve features a durable ASTM B148 C95800 aluminum bronze body and trim, ensuring superior corrosion resistance for marine, offshore, and industrial applications. With a side-entry design, this valve provides efficient flow control and reliability. Available with flat face (FF) or raised face (RF) flanged ends, it meets stringent industry requirements. As a leading supplier, we deliver top-quality ball valve solutions for demanding environments.

Detail Information

Valve Description:
187301032 Aluminium Bronze Ball Valve
Design Standard: API 6D, BS 5351, ASME B16.34
Structure: 2pcs Body, Side Entry, Bolted Bonnet, Soft Seat
Nominal Size: 18 Inch, DN450
Nominal Class: 300 LB
Bore Type: Full Bore or Reduced Bore
End Connection: FF or RF Flanged
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800, ASTM B150 C63200, Monel
Seat Insert: RPTFE
Face to Face: ASME B16.10
Test and Inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-Static Device, Fire Safe, Anti-Blowout Stem, Emergency Sealant Injection, Low Emission(Optional), DIB (Optional), Aluminium Bronze for Sea Water Service

Product Range:
Body Material: Aluminium Bronze
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
End Connection: RF, FF
Working Temperature: -26°C - +150°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
