2-1/2 IN Swing Check Valve, 150 LB, RF, A216 WCB, API 594

Key Specifications / Features

Model no. : 1841021

Located in China, our API 594 Swing Check Valve offers robust performance with its full-opening design and lever operation. Designed for precise control, it is sized at 2-1/2 inches (DN65) and meets Class 150 LB specifications. Engineered to API 594 standards, this valve features raised face (RF) flanged ends, ensuring secure installation and effective sealing. It is crafted to excel in diverse industrial environments, providing dependable flow control and facilitating smooth operations. Whether in chemical processing, petrochemical plants, or other demanding sectors, our valve combines durability, efficiency, and compliance with international standards, making it a reliable choice for critical applications.

Detail Information

API 594 Swing Check Valve, 2-1/2 Inch, Class 150 LB, RF Flanged, ASTM A216 WCB, Trim 8


Product Description


1841021 Swing Check Valve
Design Standard: API 594, API 6D, BS 1868
Structure: Bolted Bonnet
Body Materials: ASTM A216 WCB, ASTM A351 CF8, CF8M, ASTM A352 LCB, 4A, 5A, C95800
Trim Materials: ASTM A182 F6A, F304, F316, F51, F53, F55
Size Range: 2-1/2 Inch, DN65
Pressure Rating: Class 150 LB
Operation: Lever
Face to face: ASME B16.10
Test and Inspection: API 598
Bore Type: Standard Bore or Full Bore
Key Features: Full Opening design available, Bolted Bonnet, Operation Lever design Available
End Connection: RF Flanged

Product Range


Body material: Alloy Steel, Carbon Steel, Stainless Steel, Al-bronze
Size Range: 1/2 Inch - 48 Inch, DN15-DN1200
Pressure Range: Class 150 LB - 2500 LB
End connection: Raised Face (RF), Ring Type Joint (RTJ), Butt Weld (BW)
Working temperature: -196°C - +450°C
Operation: Not Applicable (Manual or actuated available for special request)
