Key Specifications / Features
Introducing our premium API 594 Swing Check Valve, expertly manufactured in China to meet rigorous industry standards. This high-quality valve features a bolted bonnet and is constructed from durable ASTM A216 WCB material, ensuring long-lasting performance. With a trim 8 design, this valve is built for a 40-inch size and operates at Class 150 LB. It adheres to BS 1868 and API 6D specifications, guaranteeing reliable and efficient operation. The RF flanged end design ensures easy installation and maintenance. Ideal for various industrial applications, our swing check valve offers exceptional reliability and performance. Choose our API 594 Swing Check Valve for superior quality and dependability.
API 594 Swing Check Valve, Class 150 LB, RF Flanged, Bolted Bonnet, 40 Inch, A216 WCB Body with Trim 8
| Valve Descriptions |
1841038 Swing Check Valve |
| Design Standard |
API 594, BS 1868, API 6D |
| Structure |
Bolted Bonnet |
| Nominal Size |
40 Inch |
| Nominal Class |
150 LB |
| Key Features |
Bolted Bonnet, Full Opening design available, Operation Lever design Available |
| Body Material |
ASTM A216 WCB, ASTM A351 CF8M, CF8, ASTM A352 LCB, 4A, 5A, C95800 Alloy |
| Trim Material |
ASTM A182 F6A, F304, F316, F51, F53, F55 |
| Bore Type |
Full Standard Bore(BS 1868, API 594) or Bore(API 6D) |
| Face to Face |
ASME B16.10 |
| Test and Inspection |
API 598 |
| Operation |
Lever |
| End Connection |
RF Flanged |
Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum-Bronze
Normal diameter: 1/2 Inch - 48 Inch (DN15-DN1200)
Pressure Range: Class 150 LB - 2500 LB
Working Temperature: -196°C to +450°C
Operation: Not Applicable (Manual or actuated available for special request)
End Connections: Raised Face (RF), Ring-Type Joint (RTJ), Butt Weld (BW)
